MR 780

Technical specifications
SENSITIVITY FM
-108 dBm
FREQUENCY RANGE FM
87.5 – 108 MHz
FREQUENCY RANGE DAB/DAB+
174.928 – 239.2 MHz (Band III)
POWER CONSUMPTION
s0 5 Max 300 W
FREQUENCY RESPONSE
CD/Tuner/Aux/Line/Tape: 6 Hz – 90 kHz (-3,0 dB) 20 Hz – 20 kHz (+/-0,3 dB) Phono: 20 Hz – 20 kHz (+/-0,8 dB) Subsonic Filter : 16 Hz, 18 dB/Oct.
INPUT SENSIVITY
CD/Tuner/Aux/Line/Tape: 470 mV/100 kΩ Phono MM: 5 mV/47 kΩ
DIGITAL INPUTS
Supported bit depth: 16/24bits Supported sampling frequencies: 44.1/48/88.2/96/176.4/192kHz USB 2.0, type B connector 1. optical (Toslink™) 2. coaxial (cinch)
BLUETOOTH® INPUT
Bluetooth® 4.0 / Qualcomm® aptX™
DIMENSIONS (WXHXD)
433 x 132 x 317 mm (360 mm incl. controls and connectors)
COLOR
Black
WEIGHT
8.9 kg
