Nad

Nad D 3045

Nad D 3045

€949,00 EUR
€949,00 EUR
Sale Sold out
Shipping calculated at checkout.

✅Promokodu izmanto pie pasūtījumā noformēšanas

✅Use promocode at checkout

✅Промокод используй при оформлении заказа

Color

📞 Premium HIFI contacts

PremiumHIFI favicon

+37129541259

arkadijs.zenins@outlook.com

Demo Room: Augusta Dombrovska 13-34, Riga (call before visiting)

PremiumHIFI

Shipping Terms

  • Shipping method: Standard
    Shipment cost:
  • EU 20€
  • LT, EST 5€
  • LV 2€
  • RU, USA 200€
  • Other countries 200€
  • Dispatched usually 2 - 5 business days after order placement
  • Some times, dispatched up to 20 business days, we will inform additional, after order placement.

https://premiumhifi.lv/policies/shipping-policy

Nad D 3045 integrated amplifier
  • THD (20Hz – 20kHz)
  • <0.003% at 2V out
  • Signal-to-Noise Ratio
  • >100dB (IHF, A-weighted, ref. 500mV out, unity gain)
  • Channel separation
  • >85dB (1kHz)
    >80dB (10kHz)
  • Input impedance (R and C)
  • 47kohms + 220pF
  • Maximum input signal
  • >5.5Vrms (ref. 0.1% THD)
  • Output impedance
  • 400 Ohms
  • Input sensitivity
  • 82mV (ref. 500mV out, Volume maximum)
  • Frequency response
  • ±0.2dB (20Hz – 20kHz)
  • Maximum voltage output – IHF load
  • >4V (ref. 0.1% THD)

PHONO INPUT / PRE OUT

  • THD (20Hz – 20kHz)
  • <0.015% at 2V out
  • Signal-to-Noise Ratio
  • >82dB (200 Ohm source, A-weighted, ref. 500mV out)
    >76dB (MM cartridge source, IHF; A-weighted, ref. 500mV out)
  • Input sensitivity
  • 1.35mV (ref. 500mV out, Volume maximum)
  • Maximum input signal at 1kHz
  • >90mVrms (ref. 0.1% THD)
  • Frequency response
  • ±0.3dB (20Hz – 20kHz)

LINE INPUT / HEADPHONE OUT

  • THD (20Hz – 20kHz)
  • <0.003% at 120mW
  • Signal-to-Noise Ratio
  • >90dB (32 Ohm load; A-weighted, ref. 500mV out, unity gain)
  • Frequency response
  • ±0.3dB (20Hz – 20kHz)
  • Output impedance 2 Ohms
  • Maximum headphone output – 32 Ohm load <8V (ref. 0.1% THD)

GENERAL SPECIFICATIONS LINE INPUT/SPEAKER OUT

  • Continuous output power into 4 and 8 Ohms
  • 60W (ref. 20Hz-20kHz at 0.03% THD, both channels driven)
  • THD (20Hz – 20kHz)
  • <0.005% (at 1W, 4 and 8 ohms)
  • Signal-to-Noise Ratio
  • >98dB (A-weighted, 500mV input, ref. 2.828V out in 4 Ohms)
  • Clipping power
  • >80W (at 1kHz 4 Ohms 0.1% THD)
  • IHF dynamic power
  • 8 Ohms : 80W
    4 Ohms : 150W
    2 Ohms : 200W
  • Peak output current
  • >18A (in 1 Ohm, 1ms)
  • Damping factor
  • >300 (ref. 8 Ohms, 20Hz to 6.5kHz)
  • Frequency response
  • ±0.3dB (20Hz – 20kHz)
  • Channel separation
  • >75dB (1kHz)
    >70dB (10kHz)
  • Input sensitivity
  • 260mV (for 30W in 4 Ohms)
  • Supports bit rate/sample rate
  • up to 24 bit/192kHz (digital source)
    up to 24 bit/384kHz (computer source)
  • Standby power
  • <0.5W

DIMENSION AND WEIGHT

  • Gross dimensions (W x H x D)*
  • 70 x 235 x 265 mm
    2 13/16 x 9 5/16 x 10 7/16 inches**
  • Net weight
  • 3.6kg (7.9lb)
  • Shipping weight
  • 2.6kg (5.7lb)

View full details
