Nad M23

Nad M23

Regular price €4.299,00 EUR
Regular price Sale price €4.299,00 EUR
Sale Sold out
Tax included. Shipping calculated at checkout.

Premium HIFI contacts

+37129541259

arkadijs.zenins@outlook.com

Shipping Terms

  • Shipping method: Standard
    Shipment cost:
  • EU 20€
  • LT, EST 5€
  • LV 2€
  • RU, USA 200€
  • Other countries 100

https://premiumhifi.lv/policies/shipping-policy

ANALOG AUDIO INPUT/SPEAKER OUT


  • Input impedance (R and C)
  • Single-ended: 56 kohms + 200 pF Balanced: 56 kohms +200 pF
  • Frequency response (1W into 8 Ohms)
  • ±0.06dB (20-20kHz)
  • Rated output power into 8 Ohms and 4 ohms(Stereo mode) 80 W (ref. 20 Hz-20 kHz at rated THD, both channels driven)
  • >200W into 8 Ohm, >380W into 4 Ohm
  • Rated output power into 8 Ohms (Bridge mode, ref. 20 Hz-20 kHz at rated THD, both channels driven)
  • >700W into 8 Ohm
  • THD (20 Hz – 20 kHz)
  • <0.00069% (XLR), <0.0013% (RCA)
  • Signal-to-Noise Ratio
  • >101.7 dB (1W into 8 Ohm)
  • >127 dB (200W into 8 Ohm)
  • Clipping power (Stereo mode, at 1 kHz 0.1 % THD)
  • >210 W (0.1 % THD 1 kHz 8 ohms)
  • Clipping power (Bridge mode, at 1 kHz 0.1 % THD)
  • > 770W
  • IHF dynamic power (Stereo mode, at 1 kHz)
  • 8 ohms: 260 W
  • 4 ohms: 520 W
  • IHF dynamic power (Bridge mode, at 1 kHz)
  • 1017W
  • Peak output current
  • >25 A (in 1 ohm, 1 ms)
  • Damping factor
  • >800 (ref. 8 ohms, 20 Hz to 6.5 kHz)
  • Frequency response
  • ±0.06 dB (stereo), ±0.054 dB (bridged) 20 Hz -20 kHz -3 dB at 60 kHz
  • Channel separation
  • High gain RCA: >97dB, Low gain XLR: >115dB (1kHz)
  • High gain RCA: >75dB, Low gain XLR: >96dB (10kHz)
  • Stereo Mode input sensitivity (for 200 W in 8 ohms)
  • Low gain: 4.5V (low gain), 2.5V (Mid gain), 1.4V (High gain)
  • Stereo Mode Gain
  • 19dB (low), 23.9dB (mid), 29.2 (high)
  • Bridge Mode Gain
  • 25.1dB (low), 30dB (mid), 35.2 (high)
  • Standby Power
  • <0.5W

DIMENSIONS AND WEIGHT

  • Gross dimensions (W x H x D)
  • 435 x 133 x 396 mm (17 1/8 x 5 1/4 x 15 5/8 inches)
  • Net Weight
  • 9.7 kgs / 21.4 lbs
  • Shipping Weight
  • 17.5 kgs / 38.5 lbs
View full details
