REL

REL HT/1003 MKII

REL HT/1003 MKII

Regular price €799,00 EUR
Regular price Sale price €799,00 EUR
Sale Sold out
Tax included. Shipping calculated at checkout.
Color

Premium HIFI contacts

+37129541259

arkadijs.zenins@outlook.com

Shipping Terms

  • Shipping method: Standard
    Shipment cost:
  • EU 20€
  • LT, EST 5€
  • LV 2€
  • RU, USA 200€
  • Other countries 100

https://premiumhifi.lv/policies/shipping-policy

Specifications

TYPE

Closed box, front-firing driver

ACTIVE DRIVER SIZE & MATERIAL

12 in., 300mm long-throw, CarbonGlas™ cone structure, inverted carbon fibre dust cap, steel chassis

PASSIVE RADIATOR SIZE & MATERIAL

NA

LOW FREQUENCY EXTENSION

-6dB at 22 Hz

INPUT CONNECTORS

Dual purpose Low Level stereo RCA or LFE RCA

OUTPUT CONNECTORS

Daisy Chain Low Level stereo RCA or LFE RCA

POWER OUTPUT

500 watts (RMS)

AMPLIFIER TYPE

NextGen5 Class D

WIRELESS CAPABILITY

HT Air Wireless (Optional), Zero Compression Single Large Scale Integrated Chip

DUAL PARAMETRIC FILTER

N/A

Protection System

FULLY ELECTRONIC SET SAFE

Yes

D.C. FAULT

Yes

OUTPUT SHORT

Yes

MAINS INPUT VOLTAGE

220-240 volts, 110-120 volts for certain markets

FUSES

4 Amp semi delay 230b, 4 Amp semi delay 115b operation

Dimensions

W X H X D

16.25 in. x 15.25 in. x 17.25 in. (413mm x 387mm x 438mm)

NET WEIGHT

43.2 lbs. (19.6kg)

FINISH

Horizontally Oriented Lined Grained Black Composite Cabinet, 15mm Top Plate, finished in 5 coats of Hand rubbed High Gloss Black Lacquer

Supplied Accessories

MAINS LEAD

Yes

NEUTRIK SPEAKON

NA

INTERCONNECT

No

USERS MANUAL

Yes

In the interest of product development, REL Acoustics Limited reserve the right to vary these specifications without notice.
