🧾 Overview
Matrix Audio NA-1 is a pure Class A balanced headphone amplifier and preamplifier for demanding desktop and full-size headphone systems. It delivers fully discrete amplification, dual gain modes, powerful balanced output and preamp outputs for active speakers or power amplifiers.
✅ Key Features
- ✅ Fully discrete pure Class A balanced circuit
- ✅ Four independent amplification units for balanced operation
- ✅ 6.35mm single-ended, 4.4mm balanced and 4-pin XLR balanced headphone outputs
- ✅ One XLR and two RCA analog inputs
- ✅ XLR and RCA pre-out for active speakers or power amplifiers
- ✅ Dual gain modes for both headphone and preamp outputs
- ✅ 80W potted toroidal transformer and up to 39000µF capacitor array
📊 Technical Specifications ▼
| Parameter | Value |
|---|---|
| Device type | Headphone amplifier / preamplifier |
| Analog inputs | 1 × XLR balanced, 2 × RCA single-ended |
| Headphone outputs | 6.35mm single-ended, 4.4mm balanced, 4-pin XLR balanced |
| Pre-outs | XLR balanced, RCA single-ended |
| Input impedance | XLR 47kΩ; RCA 47kΩ |
| Pre-out frequency response | 20Hz–20kHz (+0, -0.1dB), 140kHz @ -3dB |
| Pre-out SNR | 121dB @ +15dB A-weighted; 124dB @ +21dB A-weighted |
| Pre-out THD+N | <0.0003% @ 20Hz–20kHz |
| Headphone frequency response | 20Hz–20kHz (+0, -0.1dB), 170kHz @ -3dB |
| Headphone SNR | 120dB @ +17dB A-weighted; 123dB @ +23dB A-weighted |
| Headphone THD+N | <0.0007% @ 20Hz–20kHz |
| Single-ended output power | 7W @ 33Ω; 1.1W @ 300Ω; 580mW @ 600Ω, 1% THD |
| Balanced output power | 18W @ 33Ω; 4.5W @ 300Ω; 2.3W @ 600Ω, 1% THD |
| Output impedance | Pre-out <20Ω; headphone <1Ω |
| Trigger | Input DC 6–12V <10mA; output DC 12V/50mA max |
| Power | AC 100–120V or AC 220–240V; standby <1W; idle 35W; max <80W |
| Dimensions | 330 × 275 × 97 mm |
| Weight | 6.16 kg |
| Bluetooth / Wi-Fi | N/A |
📦 What’s in the Box
- 🎛️ Remote control ×1
- 🔌 Power cable ×1
- 📖 User manual ×1
- 🛡️ Warranty card ×1
🔄 Compatibility
Use NA-1 with DACs, streamers, CD players, active speakers, power amplifiers and demanding headphones from low to high impedance. It is especially suitable for Matrix Audio N Series systems with NT-1 and ND-1.
📦✈️ Shipping & Returns
- 📦 Insured worldwide delivery
- 🔄 14-day return policy
- 🛡️ 2-year EU warranty
📝 Reviews
💬 “Be the first to leave a review – share your experience and help others!”
⚠️ Warning
Warning: with 18W balanced output, the volume knob is not a decoration; treat it like a power tool for headphones.
